| Item/Parameter | MM-0100CT | MM-0250CT | MM-0350CT |
| Rated Speed(RPM) | 3200/48VDC | 3400/48VDC | 3400/48VDC |
| TG Feedback(V/1000RPM) | 2.5 | 2.5 | 2.5 |
| Max.Voltage(V) | |||
| Max.speed(Within 20 mins.)(RPM) | |||
| Continuous Stall Torque(Nm) | 0.5 | 0.8 | 1.4 |
| Continuous Stall Current(Amps) | 4.8 | 8.0 | 9.0 |
| Max.Current(Amps) | 20.0 | 38.0 | 48.0 |
| Peak Stall Torque(Nm) | 2.0 | 3.8 | 7.4 |
| Armature Resistance Less Brushes(Ohms) | 6.0 | 2.7 | 2.7 |
| Max.Temperature(℃) | 85.0 | 85.0 | 85.0 |
| Motor Weight(Kgs) | 2.2 | 3.4 | 4.2 |
| Specification | 2.5V/1000RPM | |
| Tachometer(TG) Connection | TG+ | RED |
| TG- | BLACK | |
| M.O.H. | GRN | |
| M.O.H. | WHT |
